Addlestone BH209 Single Channel Video Distribution Amplifier
Technical Specification
Features:
- Make: Addlestone
- Model code: BH209
- Video Distribution Amplifier: Yes
- No of Video Inputs: 1
- No of Video Outputs: 2
Additional info:
Addlestone’s BH209 is a single channel Video Distribution Amplifier that when used on its own will split a video signal into two identical outputs with no loss of signal strength or signal quality.
Read moreMake | Addlestone |
---|---|
Manufacturer | Addlestone Electronics Limited |
Category | Video Surveillance>Video signal devices & accessories |
Model code | BH209 |
Video Distribution Amplifier | Yes |
No of Video Inputs | 1 |
No of Video Outputs | 2 |
Bandwidth MHz | 4.4 |
Differential Gain % | < 3 |
Video Input Properties | Nominal 1.0V Pk-Pk @ 75 ohms |
Video Output Properties | Nominal 1.0V Pk-Pk @ 75 ohms |
Physical Specifications | Dimensions mm: 132 x 45 x 23 |
Environmental Specifications | Operating Temperature oC: -30 ~ +45 |
Electrical Specifications |
Voltage: 12 V DC Power Consumption: 200 mW |
Additional info |
Addlestone’s BH209 is a single channel Video Distribution Amplifier that when used on its own will split a video signal into two identical outputs with no loss of signal strength or signal quality. |
Download PDF version Download PDF version |
