Lynred, a global provider of high-quality infrared detectors for the aerospace, defense, and commercial markets announces the unveiling of ATI320, its first advanced thermal imager with embedded image signal processing.
The product’s embedded features, with a lens available as an option, aim at saving camera makers time and effort in integrating thermal imaging during the development and manufacturing process, enabling them to speed products to market.
Designed as a ready-to-use product, ATI320 simplifies the calibration process during camera assembly, relieving manufacturers from performing complex steps. A key motivation underpinning the product’s advanced design is in eliminating tricky integration steps, to extend access to infrared technology for newer thermal image market entrants.
“ATI320 marks a milestone in Lynred’s strategic development towards bringing more ambitious and innovative value-added propositions to key markets,” said Jean-Yves Dussaud, chief marketing officer at Lynred.
“This Advanced Thermal Imager is the culmination of our teams’ latest know-how and dexterity in developing image processing solutions, electronics, and software for our microbolometer technology, in which we have a 20-year legacy.”
ATI320 is suitable for camera makers in industrial, consumer equipment, and safety across a broad range of activities
ATI320 is particularly suitable for camera makers in industrial, consumer equipment, and safety across a broad range of activities, for example in Unmanned Aerial Vehicles (UAVs) for aerial thermal inspection, as its thermal imaging solutions are compact, lightweight, and low power consumption.
It provides the calibration, the associated image processing algorithms, and a lens when required.
ATI320 (16x16mm) is the most compact QVGA (320x240 pixels) resolution thermal imager available and comes with ruggedised housing. It is available in two models: ATI320L (with lens) and ATI320S (without lens). It operates as a shutterless product - providing continuous image viewing - an important function for the leisure, firefighting, and security-surveillance market applications.
In contrast to comparable solutions, ATI320 offers more flexibility in camera designs, since manufacturers can choose and optimize where to place ATI320 within the camera.
- Resolution: 320x240; 12µm pixel pitch
- NETD (Noise Equivalent Temperature Difference): f/1, 300 K scene, 20°C ambient for ATI320S version: <60mK
- Scene dynamic >100°C
- Operating T°C range: -40°C; +85°C
- Full digital product with power consumption <400mW, when an image signal processing is fully activated
- Frame rate: 60 Hz
- Standards compliance: Mil-Std-810/883
- Weight: <3g for ATI320S version; <7g for ATI320L version
