Fotech Group: Turning Fiber Optics Into Smart Security Perimeter Systems

Security breaches of borders, utility plants and airports can have catastrophic and devastating consequences, so protecting assets is vital.

The global perimeter security market is expected to reach USD29.6 billion by 2025, driven by growing terrorist threats, increased awareness of illegal immigration, planned crimes, thefts and smuggling.

Continuous monitoring system

Existing perimeter intrusion detection technologies typically rely on point sensors such as cameras that are positioned along a perimeter or border at regular intervals.

However, cameras have their limits. They can only provide line-of-sight coverage at specific points; they do not deliver continuous monitoring or provide full visibility of the entirety of the perimeter.

Asset monitoring technology

This is where LiveDETECT comes in. This real-time linear asset monitoring technology from Fotech, a bp Launchpad company, turns fiber optic cabels along a border or perimeter into an entire, continuous length of sensors, monitoring the asset at all times.

“The sheer distance of some borders and perimeters means it is impossible to achieve true round-the-clock monitoring of the perimeter length with physical patrols or CCTV.”

“The solution of positioning cameras every few metres is not feasible from an economic point of view yet leaving gaps in coverage is an open invitation for threats and intrusions,” says Ken Crowe, Security Industry Sector Manager for Fotech.

Distributed Acoustic Sensing (DAS) technology

Helios DAS analyzes the changes to identify and to categorize the disturbance eventLiveDETECT uses Distributed Acoustic Sensing (DAS) technology, which sends thousands of pulses of light along with fiber optic cables every second and monitors the pattern of light reflected back. The fiber optic cable picks up any acoustic or vibrational energy, which changes the light pattern that is reflected back to the hardware, Helios DAS, indicating a disturbance of some kind.

Thanks to advanced algorithms and processing techniques, Helios DAS analyzes these changes to identify and to categorize the disturbance event, such as walking near or interfering with a boundary, placing a ladder on a fence, or digging near a perimeter.

Each type of disturbance has its own signature, and the technology can tell an operator in real-time, what happened, exactly where it happened, and when it happened. More importantly, it can also filter out background noise, adapting its response for high-risk or low-risk zones along the perimeter.

Perimeter security

“If a perimeter is near a frequently-used track for runners, we can ensure that the normal activity doesn’t set off alarms.”

“However, a personnel signature at 3 am or one that stops near the fence perimeter would be viewed as unusual. Any deviations from a normal pattern of behavior can be programmed and an alert raised,” says Crowe.

If a security breach is detected and there is an attempted intrusion, the system alerts the Alarm Management Server and security personnel so they can take the most appropriate action. There are three levels of alert: green, amber, and red. Red is the highest alert level, usually when someone or something could imminently breach the inside of the perimeter.

Easily integrated

LiveDETECT should be part of a foundational security strategy. It is easily integrated into existing security systems, working in conjunction with cameras, sentry posts, and unmanned aerial vehicles (UAVs) also known as drones, to provide situational awareness and to enhance overall protection.

“What LiveDETECT delivers is a perimeter with no security gaps. This increases the efficacy and accuracy of identifying potential breaches, as well as boosting the speed of response through the real-time detection of incidents anywhere on the perimeter,” Crowe adds.

Active intrusion alert

LiveDETECT is covert and intruders will be unaware of its existence With an active intrusion alert, LiveDETECT can provide information on where cameras should be pointing. Alternatively, LiveDETECT can send GPS coordinates of the on-going disturbance to a UAV, which automatically launches itself to investigate more fully.

As fiber optic cables are typically buried in the ground, LiveDETECT is covert; intruders will be unaware of its existence. Furthermore, DAS is not affected by the weather, cameras would not be beneficial in a sandstorm or a snowstorm, whereas LiveDETECT can continue to operate reliably.

Robust system

“LiveDETECT is a robust system into which we can build extra safe-guards. The fiber optics can be configured in a dual-loop and run in parallel to provide redundancy, and maintain coverage if a sensing cable is maliciously or accidentally cut,” Crowe says.

The monitoring system software can also be mirrored to a secondary site, so alerts are recorded in two locations, ensuring the responsibility does not lie with one person.

Security for the future

During the last decade, technological advances have helped increase the scope of perimeter security systems. Perimeter security systems have historically been used to detect and to deter intrusions in military facilities and critical infrastructure.

Today, they are being adopted in commercial and transportation sites as well as residential gated communities in high-risk countries. LiveDETECT fills the gaps in the border and perimeter surveillance efforts, delivering continued monitoring compared to existing technologies, improved security, reduced human and drug trafficking, and detection of tunnel digging.

Crowe concludes, “LiveDETECT’s ability to provide continuous monitoring of an entire perimeter and to raise alerts in real-time, gives security teams the comprehensive overview they need to manage their operations and respond to threats effectively.”
