Airports & Ports Security Applications
Dallmeier offers comprehensive security solutions for all areas of application around airports. Specifically, in the area of cameras a wide range of systems allow customers to tackle all of their safety and security challenges and be able to comply fully with operational and regulatory requirements. On top of that, Dallmeier supplies video management solutions that not only give operators an exhaustive overview of security-relevant events, but also allow the video data to be analyzed with a vi...
LAN airline, one of the most important airline companies in Latin America, is based in Lima, Peru. The airline company operates scheduled domestic and international services, controlling over seventy percent of the domestic market. Its main base and maintenance center are located in Jorge Chávez International Airport, Lima, which is a significant transfer hub and aviation infrastructure of South America. The LAN airline deploys its surveillance system with Dahua solutions for its office...
Though it has been statistically proven that taking a plane is no riskier than taking a bus, people do have reasons to put extra caution on air travel safety, especially in a time replete with terrorist threats. A major line of defense must be the various sections of the airports, which, as a gateway to the outside world and transportation hub of the city, has always been on the top of the safety list of the government and all related authorities. Dahua’s Airport Solution is an intelligen...
Manchester-Boston Regional Airport opened to serve the state of New Hampshire and the surrounding New England community in 1927, a little over two decades after the Wright brother’s first powered flight. Located three miles south of central Manchester, the Manchester-Boston Regional Airport is the fourth largest passenger and third largest cargo airport in New England. The airport is also the busiest in the state, qualifying under the Federal Aviation Administration (FAA) as a “small...
USS Iowa: A Naval Treasure Affectionately known as the “Battleship of Presidents” for having played host to more U.S. presidents than any other battleship, the USS Iowa is one of the most storied vessels in the history of the Navy. Originally commissioned in 1943, the Iowa saw significant action during both World War II and the Korean War. One of the battleship’s first missions was to escort President Franklin Delano Roosevelt across the Atlantic in November of that year for a...
Airports and ports are subject to a tough balancing act when it comes to security measures. On the one hand, these locations must maximize the movement of passengers and cargo to ensure a happy customer experience, while at the same time exercising security measures that will ensure their safety. Access Points In Transport Hubs Airports and ports are large areas with many access points, a necessity to facilitate the efficiency needed to handle the large volumes of traffic they generate. This a...
Two giant video surveillance companies have responded to a United States government ban on use of their products included in the 2019 National Defense Authorization Act (NDAA). Both Hangzhou Hikvision Digital Technology Company and Dahua Technology Company are mentioned by name in a section buried in the giant military reauthorization bill. A ban on use of their products will take effect “not later than one year after” the law is enacted. Response From The Manufacturers Hikvision’s statement expresses disappointment with the version of the 2019 NDAA passed by both chambers of the U.S. Congress Hikvision’s statement expresses disappointment with the version of the 2019 NDAA passed by both chambers of the U.S. Congress. “This legislation was quickly drafted without sufficient evidence, review, or investigation to warrant the video surveillance technology restrictions outlined in section 889,” says Hikvision. “The process resulted in an ambiguous provision with potentially far-reaching implications for American business and represents a rejection of the U.S. government’s commitment to use a standards-based approach when evaluating security risks in federal procurement.” Dahua was less direct and did not specifically mention the ban in its statement. “Although local laws and regulations may present challenges, we never lose sight of our goals — to provide top-tier products and services for the North American market,” says the statement from Zhejiang Dahua Technology Ltd. The rest of the statement centers on Dahua’s ongoing commitment to the video surveillance market and addresses possible motivations for the ban (see below). Impact On Contractor Business Dahua’s statement expressed its ongoing commitment to the video surveillance market Hikvision also cited a recent article published in The Hill that quoted Chris Nickelson, a Missouri-based contractor, who argued that a ban on Hikvision products would actually harm small American businesses like his. According to the article, Nickelson said allegations against Hikvision have hurt his business, and he decried a lack of evidence supporting the allegations. “Somebody still needs to show me that there’s any real meat and potatoes behind any accusations that have been made towards Hikvision,” Nickelson is quoted in The Hill. The rest of Hikvision’s statement: “Hikvision is committed to complying with all applicable laws and regulations and has made efforts to ensure the security of its products go beyond what is mandated by the U.S. government, including certification under the Federal Information Processing Standard (FIPS) 140-2 and opening our Source Code Transparency Center (SCTC), which makes the company’s source code available for review by law enforcement authorities and government agencies in the U.S. and Canada.”We understand that in today’s security industry, cybersecurity is the biggest challenge" Company Statement On The NDAA Here is more of Dahua’s statement on the National Defense Authorization Act: “Dahua Technology is a global leading IoT video surveillance solution provider operating in 37 countries and dedicated to bringing our customers innovative solutions. Dahua Technology has been publicly traded on Shenzhen stock exchange market since 2008 and is not a government-owned entity. We understand that in today’s security industry, cybersecurity is the biggest challenge. We have provided remedies to correct those issues with our customers. We take cybersecurity very seriously by implementing a seven-module cybersecurity baseline into our product design. Meanwhile, we continue to work with 3rd party partners like DBAPP Security and Synopsys Technology, to rigorously test our products to combat against current cybersecurity vulnerabilities."To personalize our interaction with customers at this event, Hikvision will not have a booth on the GSX show floor" Dahua’s statement continues: “With over 6,000 R&D Dahua professionals, we strive to provide secure products and solutions to our valued customers to secure what they care about. Although local laws and regulations may present challenges, we never lose sight of our goals — to provide top-tier products and services for the North American market. We will continue to invest in resources and employees to ensure our customers and partners retain the highest quality of services to support future growth in this market. "We will continue to invest in resources and employees to ensure our customers and partners retain the highest quality of services to support future growth in this market.” Hikvision Comments On GSX Presence Hikvision has also issued a statement about its downsized presence at the upcoming GSX trade show (formerly ASIS) in Las Vegas. A Hikvision spokesperson confirmed that the decision to abandon Hikvision’s large booth presence was made earlier this summer and was not a result of the ban. Here is Hikvision’s statement about GSX: “As in previous years, Hikvision will be well represented at the GSX show in September in Las Vegas. To personalize our interaction with customers at this event, Hikvision will not have a booth on the GSX show floor. Instead, a contingency of Hikvision professionals will attend the conference and host partner meetings and product demonstrations in meeting facilities throughout the trade show. "As a total solution provider, Hikvision looks forward to meeting with end users, A&E consultants, integrators and other partners to discuss how Hikvision's full suite of products can help address the challenges facing security directors and the broader C-Suite.”
At ISC West 2018, visitors to the Genetec Inc. booth #26065 will be able to learn about the company’s new range of market-specific solutions specifically developed to address the needs of airports, cities, educational institutions, retailers, and transportation customers. “By leveraging the growing availability of valuable yet untapped sources of data, these portfolios create a host of new opportunities for organisations to find synergies between their security, operations, and business intelligence needs,” comments Jimmy Palatsoukas, Director of Product Marketing at Genetec. Genetec Citigraf is a decision support system ideally suited for law enforcement, emergency services, and public safety agencies Genetec Airport Sense At ISC West, airport customers will be particularly interested in looking at Genetec Airport Sense, an advanced operational analytics solution that correlates data provided by existing security sensors to produce actionable intelligence about passenger flow, airport security, and overall operations. Attendees will also be able to see how Genetec Security Center, a unified security platform, Genetec Clearance, a digital evidence management system, and Genetec Mission Control, a collaborative decision management system, are helping leading airports around the world heighten security, improve operations, and grow retail revenue. Genetec Citigraf Already installed in several cities around the world, Genetec Citigraf is a decision support system ideally suited for law enforcement, emergency services, and public safety agencies. Citigraf was first introduced in the city of Chicago, where it is helping to improve collaboration, shorten the first-response time of reported incidents, and significantly reduce crime. Featuring a powerful correlation and analytics engine, as well as a unified view of public safety operations, Citigraf instantly detects and displays relevant information from disparate systems for inter-agency collaboration. The proliferation of new surveillance systems, body-worn cameras, in-car video and mobile phones has created more ways to gather evidence, while exponentially increasing the quantity of data collected. A digital evidence management system, Genetec Clearance allows cities, police officers, investigators, and security managers to collect, manage, and share digital evidence from a variety of sources. To help solve challenges such as traffic congestion, roadway accidents, and parking scarcity, Genetec recently introduced Genetec Traffic Sense Genetec Traffic Sense The efficient flow of people, vehicles, and goods throughout cities and communities is a fundamental aspect of everyday life and business activities. To help solve challenges such as traffic congestion, roadway accidents, and parking scarcity, Genetec recently introduced Genetec Traffic Sense. This unified traffic operations platform brings together traditional traffic operations systems with security and incident response platforms and uses advanced analytics to detect road incidents and slowdowns, automates response, and provides operators with a consolidated view of events. Genetec Security Center And Mission Control Teaching, research, and learning happen best when faculty, staff, and students feel safe. With thousands of students and staff to protect, sprawling campuses, and emerging threats, campus security is often left feeling overwhelmed. Working together, Genetec Security Center and Mission Control increase situational intelligence and enable security personnel to prepare for, and effectively respond to, common occurrences and emergency situations. By unifying all aspects of campus security, such as access control, video, ALPR (Automated License Plate Recognition), communications, and intrusion, Security Center enhances the efficiency of campus police. Not only do they benefit from a global view of all their buildings and campuses, but they are better equipped to centrally act on threats at a moment’s notice. Genetec Retail Sense Genetec Retail Sense enables brick and mortar retailers to increase operational intelligence to enhance customer service Retailers today are behooved to gather and rely on the same insightful customer analytics that online merchants can harvest automatically. Security Center offers retailers enterprise-wide visibility of sales floors, point-of-sale (POS) and cash-handling areas, distribution centers, and parking facilities so that they can efficiently safeguard staff, patrons, buildings and equipment. When used with Security Center, Genetec Retail Sense enables brick and mortar retailers to increase operational intelligence to enhance customer service by transforming existing video surveillance content into powerful consumer insights. Genetec solutions are designed to help public transit agencies develop and maintain the most efficient operations and processes to provide passengers with positive experiences in a secure environment. When transit and security personnel manage operations from a single, unified platform, such as Security Center, they have easy access to all the data being collected by their physical security system. With this bird’s-eye-view of their environment, they can respond quickly and knowledgeably to any incidents as they arise.
Innovative laser scanning technology from OPTEX, can now be integrated with the Genetec Restricted Security Area (RSA) Surveillance module, to deliver a new era in security and detection in outdoor and indoor environments for airports and other critical infrastructure sites. Via the RSA Surveillance module, OPTEX’s award-winning REDSCAN laser sensors can now send real-time events and alarm data to the Genetec unified security platform, Security Center, alerting control room operators to any intrusion in the surveillance area. Intrusions can be tracked on site maps to enable operators to respond to threats even more quickly and accurately. The REDSCAN laser sensors provide highly customizable virtual walls and ceilings which can be used to protect a perimeter line, but also specific areas. In the case of an airport, this might include entrances to hangars, gates and other restricted areas including baggage halls. The virtual ceiling or panes can protect rooftops and open areas (to create ‘sterile zones’), as well as being able to detect objects thrown over partition walls between secured and non-secured areas, such as passports and contraband. Laser Scan Technology For Detection Precision OPTEX REDSCAN is an extremely reliable system, whatever the internal lighting or external weather conditions. The target object can be defined by its size and the speed it is moving; when used in outdoor applications, it can ignore most wildlife such as rabbits, birds, and rodents. “We are pleased to welcome OPTEX as a partner,” says Georges Tannous, Director of Strategic Alliances at Genetec. “The technology and detection precision provided by their LiDAR devices can help benefit airport, mass transit and critical infrastructure customers.” These sentiments were echoed by Ryosuke Miwa, Senior General Manager of Global Security Division from OPTEX Japan. “We are delighted with the integration of our laser detection sensor within the Genetec RSA Surveillance module. “Intrusion detection along the perimeter, or a controlled area inside a building, can play a critical role in an overall security solution, especially for airports and other high security sites that Genetec software is often specified for. The integration adds another layer of awareness and control to the system’s operator.” To add a REDSCAN laser on a Genetec RSA Surveillance module, a device licence will be required. It will be supported on any Security Center Pro or Enterprise version 5.6 SR1 and later releases.
Delta Scientific, a manufacturer of counter-terrorist vehicle control systems used in the United States and internationally, has announced that its new patent pending crash rated TB100 portable bollard system will let law enforcement and other security providers promptly block access to temporary venues where vehicles can be used as weapons against large numbers of pedestrians. Individual portable bollards provide vehicle barricades in applications such as heavily traveled narrow walkways and roadways or any area that a vehicle can get through. They can also be used as substitutes until permanent bollard systems get installed. TB100 Portable Bollards Up to five TB100 portable bollards can be linked together with a cable system and be placed on a road's surface to create immediate protection for a span of 20 feet (6 m). No other installation procedures, excavations or sub-surface preparations are required. Certified testing demonstrates that a TB100 portable bollard system will stop and disable a 15,000 pound (6,804 kg) vehicle traveling at 30 mph (48.3 kph), resulting in an ASTM M30, P3 rating. A single TB100 bollard absorbs 400,000 foot pounds of kinetic energy. The barriers can protect people at public events such as parades, festivals and sporting weekends "This is a remarkable result for a light-weight portable bollard system that requires no excavation or attachment to the roadway," emphasizes David Dickinson, senior vice president of Delta Scientific. "It can be placed on any stable surface such as concrete, asphalt, compacted soil or vegetation to quickly protect people and property against aggravated automobile or truck assault." Public Event Safety According to Dickinson, the TB100 temporary bollards can be used to close off streets, entrances or wide expanses such as access to pedestrian areas or even airport runways. They can be installed in conjunction with Delta's popular MP5000 portable barricade to fill in any gaps to protect people and critical infrastructures at public events such as parades, festivals, sporting weekends and any place that vehicles could attack transitory events. The combination of the portable barriers with the new portable bollards provides fast controlled vehicle access without the time and labor of installation. "From a purchasing standpoint, it can be easier to buy portable bollards and barricades than permanent solutions," adds Dickinson. "The latter are oftentimes placed into an organization's real assets budget because they are permanently installed into the ground, becoming part of the property. Such budgets can often create complex purchasing scenarios for law enforcement or public safety departments. However, purchasing portable bollards and barricades is no different than buying protective vests for personnel or new sets of wrenches for the maintenance department."
At ASIS 2017, Pelco by Schneider Electric will be showcasing a wide range of integrated surveillance technologies which drive the company’s advanced solutions capabilities. Key vertical market displays in the Pelco exhibit (booth 2309) will address challenges faced in the city surveillance, gaming, ports, and oil and gas verticals. A special feature in the Pelco exhibit will highlight how the company’s portfolio of surveillance cameras and video management platforms combine with partner technologies to seamlessly deliver end-user solutions with meaningful innovation. “Pelco is reclaiming the lead in product development and in driving advanced integrated surveillance solutions,” said David DeLisser, Director of Global Solutions Marketing, Pelco by Schneider Electric. “This year’s ASIS exhibit demonstrates our commitment to deliver solutions that provide our customers with meaningful innovation to address their specific security challenges and objectives.” Port Security Today’s airports and seaports are faced with operational challenges that impact nearly every aspect of the facility. From strict regulation requirements, to evolving terrorism threats, to theft prevention and a focus on passenger safety, these complex environments require immediate response and leave little room for error. Pelco’s Video Management System (VMS) and extensive portfolio of high-resolution network surveillance cameras provide security management with the wide area coverage and documentation they need so they can control their facility with confidence. By leveraging powerful VMS offerings with third-party solution providers, and multiple related systems such as access control and analytics, Pelco provides tailored solutions to help better protect ports. Pelco’s powerful VMS solutions ensure that gaming facilities’ surveillance and security systems are controlled with confidence Casinos And Gaming Surveillance As gaming facilities continue to evolve into multi-use, multi-business operations, their surveillance needs continue to expand and escalate. This requires a partner with end-to-end surveillance solutions that deliver the performance and quality required for mission critical applications while satisfying the specific compliance demands for gaming facilities. Pelco’s powerful VMS solutions ensure that gaming facilities’ surveillance and security systems are controlled with confidence. With features like the ability to partition systems with independent control and analytics, Pelco’s VMS platforms satisfy specific gaming application requirements. Pelco also provides a comprehensive range of imaging solutions that deliver wide area, long range, extreme close-up and panoramic coverage even in challenging lighting conditions that are ideal for virtually any gaming table, back area, casino cashier, parking area, and entry/egress coverage applications. Oil And Gas Video Solutions Hazardous environments require specialized products that comply to specific criteria and regulations. Pelco’s unique explosion-proof cameras are engineered to survive in the harshest and most hazardous environments. When deployed with Pelco’s versatile VMS solutions, these unique systems dramatically improve the control of integrated surveillance and security systems, providing users with greater situational awareness so they can make more timely decisions and execute decisive action. Enabled with SCADA integration and perimeter control analytics, Pelco delivers comprehensive surveillance and security solutions specifically designed for oil and gas facilities. City Surveillance City surveillance systems need to function as eyes on the street for law enforcement and city management officials. Pelco’s comprehensive offering of panoramic multi-sensor cameras deliver 180°, 270° and 360° views that totally surround you. When combined with any of Pelco’s advanced networked PTZ dome and fixed cameras with advanced low-light and processing capabilities, system operators have unparalleled flexibility to monitor wide areas such as parks and intersections with advanced analytics like automatic vehicle incident detection or license plate recognition analytics.
Hanwha Techwin America, a provider in global security, is building on its commitment to deliver the industry’s highest-performance video solutions with the introduction of its new Wisenet P series multi-sensor/multi-directional cameras. Available in 8 and 20 megapixel, these cameras offer unmatched performance. They are ideal for applications such as parking lots, shopping mall entrances, lobbies, station concourses and airports. "Our multi-sensor cameras have the ability to provide a wide area coverage in extreme detail with just one camera," said Ramy Ayad, Senior Product Manager, Hanwha Techwin America. "We exceeded the benchmark for multi-sensor camera technology by incorporating features such as 60fps, 150dB wide dynamic range, low light performance (0.0015 Lux B/W, 0.015 Lux color) and built-in video analytics.” Built-In Video Analytics Hanwha’s new Wisenet P series includes the PNM-9080VQ with four individual 2 megapixel sensors for a total of 8 megapixel resolution capable of 150dB WDR and 60fps (per sensor). The series also includes the PNM-9081VQ with four individual 5 megapixel sensors that deliver 20 megapixel resolution capable of 120dB WDR and 30 fps (per sensor). Both Wisenet P models include built-in license free advanced video analytics, backlight compensation, True Day/Night and digital image stabilization with a gyro sensor. The combination of H.265 compression and WiseStream II result in data reduction of up to 99% The combination of H.265 compression and WiseStream II, a complementary compression technology that dynamically controls encoding, balancing quality and compression according to movement in the image, result in data reduction of up to 99%. This translates into significant savings on bandwidth, storage and cost. Additional features of the Wisenet P cameras: 4 SD/SDHC/SDXC card slots (one for each channel), offering total storage of up to 1TB PoE+ (8 megapixel) or HPoE (20 megapixel) and 12VDC Triple codec H.265/H.264/MJPEG Hallway View Motorized varifocal lens (2.8~12mm per sensor @ 8 megapixel; 3.6~9.4mm per sensor @20 megapixel) for widest range available in the industry in a multi-sensor camera IP66/K10 rated housing
AIG, Aéroport International de Genève, is one of the most dynamic airports in Europe. In 2012 alone it handled almost 13.9 million passengers and 193.000 flights to 120 destinations, serviced by 200 different companies. Obviously, with these figures, security is an important issue and needs to be up to standard at all times. Managing Access For A Large Workforce The implemented AEOS platform controls the access of a workforce of 9,500, manages 37,500 badges, 200 organizations working at the airport’s facilities. Securing and controlling such a dynamic environment requires a flexible access control system, based on state-of-the-art technology which is able to meet present demands as well as future security requirements. Handling Multiple Access Control Technologies One of the main reasons for AIG to choose Nedap AEOS as its security management platform was its radical different architecture based on software components. AEOS software components allow the platform to support and enhance the airport’s security policy and procedures. Furthermore, changing requirements can be put into effect much more easily. Another reason to choose AEOS is its capability of simultaneously handling multiple reader and credential technologies in a single platform. Single Card Access Control Four different identification technologies are used simultaneously in AEOS access control functionality at Geneva Airport: Nedap, Mifare, Legic and Magnetic stripe, each technology serving a different purpose. The Nedap Combi card has been put into place, which combines all the required technologies, therefore increasing convenience for the users, as they do not have to carry four different cards.
Levels of security inside the Aviation industry have never been higher; mainly due to increased terrorism threat levels across the globe, combined with a worldwide rise in smuggling activity. No airport is immune from these pressures and Ghana’s ‘Kotoka International’ can now claim to meet ACC3, the highest accreditation in the aviation industry, thanks to their recent investment in the latest generation of IP CCTV systems from Hikvision. Ghana’s Kotoka International Airport Established in 1994, Aviance Ghana Ltd provides a range of ground handling services at Ghana’s Kotoka International Airport, situated just outside the capital, Accra. The airport itself is Ghana’s premier international flight center and is capable of accepting large aircrafts, such as the latest generation of Boeing 747.Aviance Ghana is one of eight companies making up the Aviance Alliance, which operates at more than 100 airport locations across 4 continents It occupies more than 650 hectares, with two large terminals for domestic/regional and international/long-haul operations that are connected by an internal walkway. Terminal 2 is the principal international departure terminal and includes restaurants, duty-free shops and two Executive lounges for First and Business Class travellers. There are also two smaller terminals dedicated solely to diplomatic flights and military operations. Aviance Ghana is one of eight companies making up the Aviance Alliance, which operates at more than 100 airport locations across 4 continents. At Kotoka, the ground services include managing all the passenger concourse facilities in Terminal 2, plus passenger check-in and baggage handling, the loading and unloading of cargo from freight flights and a cargo warehouse operation for all import and export needs. Overriding Security Objectives Given that today’s security concerns require the aviation industry to maintain very high levels of protection measures, close scrutiny of the 650 hectare site that the airport occupies and protecting passengers, aircraft and cargo were the twin key objectives for Aviance when deciding to upgrade the Airport’s CCTV system. The company also recognized that intelligently deploying the camera infrastructure would be necessary to maximize cost-effectiveness and efficiency.The new Skylink CCTV system design uses four different types of Hikvision IP camera Aviance Ghana turned to Skylinks Technical Services Ltd and tasked them with designing a solution that would enable it to meet the EU’s ACC3 accreditation, the highest accreditation in the aviation industry. In turn, Skylinks turned to Hikvision for the design of an all-IP CCTV system capable of not only meeting the current challenges facing Aviance in its operation at Kotoka International Airport, but also providing an expandable base that could rise to meet future developments. The new Skylink CCTV system design uses four different types of Hikvision IP cameras connected to a 32-channel, RAID 5 NVR over an entirely new Gigabit network infrastructure. According to Haim Atanelov, Skylinks General Manager, “The final brief for the CCTV upgrade included installation of new cameras in Aviance’s import and export cargo warehouses, both entry and exit vehicle gates, within the terminal public areas, at the biometric log-in area and associated turnstiles, and within the VIP lounge areas. “In all of these disparate areas, we were challenged by Aviance to deliver high resolution images at all times and in all lighting conditions. It is these pressures that helped us in choosing Hikvision components, with their robust build quality, excellent video quality, and quick and simple installation and operation due to the user-friendly software. It also helped that the products offer very competitive prices and are accompanied by after-sales service and technical support from a first-class team.” Clear Images In Poor Lighting Conditions Aviance is committed to phasing out the old system in favour of a totally Hikvision IP system as soon as possible" The CCTV system uses a combination of IP66-rated dome and bullet cameras with either 1.3 or 3MP resolution. A total of four DS-2CD2312-I 1.3MP Outdoor Network Mini Dome cameras were installed, two in the public areas of the terminal and two at the main gates where passengers complete the biometric log-in process and enter through the turnstiles. To complement the dome cameras, nine EXIR bullet cameras were used: five DS-2CD2212-I5 1.3 MP units for general surveillance in the warehouses together with a pair of DS-2CD2232-I5 3MP units where greater resolution was required, and two DS-2CD2632F-I 3MP Vari-focal EXIR cameras for the main vehicle entry and exit gates. “All of the cameras offer great resolution, with 3D DNR and Digital WDR as standard, together with a full complement of alarm triggers, including line crossing and motion and intrusion detection” says Haim Atanelov. “But, the true day/night capability of the EXIR infrared technology meant that they always delivered clear images, even in the warehouses where lighting conditions are not good. Both the 1.3MP and 3MP bullet cameras employed in the warehouses live up to the 50-meter IR range quoted. What’s more, the 30-meter EXIR range of the mini dome cameras deployed in the terminal building is also very useful during night time hours when the building lighting is partially shut down.The new system has already proved its worth, helping to completely seal the export warehouse in particular “We also paid particular attention to the vehicle entry and exit points, in each case choosing the 3MP Vari-focal bullet cameras for their IP66 environmental protection, high resolution, advanced night viewing capabilities and zoom.” Into The Future The new system has already proved its worth, helping to completely seal the export warehouse in particular and enabling Kotoka to meet ACC3 accreditation. Together with securing the import warehouse, which serves global airline and cargo brands such as British Airways, South African Airways, Alitalia, KLM, Virgin, DHL, Cargolux, etc., it means that the airport is well-placed to continue to attract business. “Aviance is especially pleased with the smooth integration of the Hikvision IP system with the access control system at the 4 turnstiles,” says Haim Atanelov, “something which was also carefully noted by the EU ACC3 validators. Aviance was also pleased with the integration of the new system with the existing analog CCTV system, although it did show up the difference in video quality immediately. "We have already agreed to add further IP cameras to the site and Aviance is committed to phasing out the old system in favor of a totally Hikvision IP system as soon as possible.”
Critical Infrastructure Airports, harbors and ports, railways, highways, pipelines, and bridges together make up much of the infrastructure and facilities the modern world relies upon for transportation. They are the entry and exit points for both domestic and international travel, and the critical infrastructure for the transhipment of people, freight, commodities, manufactured goods, and other cargo. Arecont Vision’s Superior Performance “Ease of installation, compatibility with our current VMS, and the new features [including] Wide Dynamic Range. Our experience has been great. Our organization requires high levels of security and with Arecont Vision’s updates to firmware we can maintain our internal network security policies.” said Safraz Samad, TPA Operations – Security Administration, Tampa International Airport. “Alberta invests a great deal of money and resources into developing and evaluating the best technological advances to provide superior performance to our customers. Arecont Vision’s megapixel cameras fit perfectly into our technology-centric approach to the market, as demonstrated by their performance in our installation at the cruise ship terminal in Valletta.” commented Karim Cassar, Technical Research Executive, Alberta. Megapixel Camera Benefits Deter and detect threats and document activities Maintain situational awareness and security Improve staff productivity Resolve security/staff and customer disputes Protect staff, travellers, customers, equipment, and goods Ability to cover more with less Increased detail equals better forensics and reduced time from police and security professionals in post event investigations Monitor daily business Forensic documentation to build cases Provide security, situational awareness, life safety Prevent fraudulent claims Application Areas Remote surveillance Facility entry/exits Loading docks Luggage and freight areas Storage areas Offices and warehouses Open spaces Parking lots/structures Roads and bridges Concourses and corridors People/vehicle counting/monitoring License plate/facial recognition
Customer Jebel Ali Port is the flagship port of DP World, a leader in international marine terminal operations and development, logistics and related services. The port is the world's largest man-made harbor and the largest container port between Rotterdam and Singapore. Located 35 kilometers to the southwest of Dubai on the United Arab Emirates Arabian Gulf coast, the port’s strategic geographic location has enabled it to act as a maritime link between the Middle East and the western hemisphere. It is a technologically advanced facility, employing state-of-the-art equipment and is a model for the industry and the region in everything from size to efficiency and security. Challenge The DP World marine control tower at Jebel Ali is an important facility for monitoring and controlling the movement of vessels in and out of the port. Physical security at the control tower was in need of upgrading and, in keeping with requirements mandated by Jebel Ali Port Security, DP World conducted a security risk assessment to determine how best to improve security at the site. Based on the assessment, DP World recommended an external video surveillance system. A basic design was developed that included 13 analog day/night box cameras and two outdoor pan-tilt-zoom (PTZ) cameras. Upon review, DP World concluded that the installation of this analog video surveillance system would also require the services of civil and electrical personnel for cabling and power needs. These additional services would add to the overall system costs as well as potentially increase the time frame for completion. DP World shelved the analog proposal and initiated a search for a more technically advanced video surveillance solution. They needed a camera system that would thoroughly cover the designated areas; require little or no external services or personnel for installation/maintenance; offer features and functionality that would enhance monitoring and operational control; be reasonably priced and ultimately provide greater detail and picture quality than would a typical analog system. Megapixel Solution DP World moved forward on the project with a new solution featuring megapixel cameras from Arecont Vision. When comparing the Arecont Vision megapixel system to the original analog system, it was evident that while the analog cameras were priced less than megapixel cameras on a per camera basis, they deliver less value when a total system cost was evaluated. The new design included two AV8185DN 180° day/night panoramic 8-megapixel dome cameras, two AV10005DN day/night 10-megapixel MegaVideo® Compact box cameras and four AV2105DN day/night 2- megapixel MegaVideo® Compact box cameras. Compared to the original design that included 13 analog cameras, the six-camera Arecont Vision megapixel system provided greater coverage with fewer cameras and significantly higher resolution images. The ability to digitally zoom into live scenes and recorded video while maintaining high resolution and wide area coverage also eliminated the need for PTZ cameras. And with Moonlight™ mode, the cameras automatically shift from color to black and white as ambient light diminishes. Megapixel Benefits Because the megapixel network cameras are PoE (Power over Ethernet) capable, the need for separate electrical cables to provide power was eliminated. Power and data is conveyed over a single network cable per camera. Using fewer cameras to effectively cover the same area also translated into infrastructure cost savings in containment works, cables and installations, which actually brought down the original cost of the system by nearly 20%, easily reflecting an improved return on investment (ROI). In addition to these advantages, the megapixel solution also contributed towards a greener environment because of fewer cables and less hardware that was needed. The Arecont Vision megapixel camera system provides superior performance and imaging capabilities than the analog system and most importantly, proved to deliver the most cost-effective video surveillance solution with tangible benefits and ROI.
Port Fourchon plays a strategic role in supplying the United States with nearly 18 percent of its oil supply, servicing over 90 percent of the Gulf of Mexico’s deepwater exploration and production. Securing such an essential portion of the Gulf Coast requires a hands-on team of security professionals to watch for unauthorized activities and enhance the safety of workers and officers. When evaluating options for a surveillance system to feed its new maritime domain awareness platform GLPC-C4 (C4), Port Fourchon officials chose Milestone XProtect® Enterprise video management software (VMS). “On a day-to-day basis, we are observing numerous points of interest throughout the port, in addition to providing a helping hand to the security officers. The video surveillance system has been taken to an entirely new level, integrating multiple systems for complete coverage. Milestone’s open platform allows us to feed video analytics and disparate cameras through it, and the entire port is benefiting immensely.” April Danos, Director of IT, Port Fourchon. The challenge: As the first land point of contact for approximately 90 percent of all Gulf of Mexico deep-water activities, including more than 600 rigs and platforms within a 40-mile radius, Louisiana’s Port Fourchon has unique safety standards to combat potentially devastating safety issues that may damage vessels, equipment, products and people working at the port. Obsolete surveillance equipment previously used to monitor the area was not sufficient to support the new C4 platform. A new video system was required to provide clearer imaging, improved storage capabilities, wider coverage and flexible video management. The solution: Milestone XProtect® Enterprise software has been deployed by Convergint Technologies to manage 64 cameras from Bosch and Pelco. With Milestone’s ability to display video in real time and its open platform architecture for integration with analytics from BRS Labs, the port’s personnel have the benefit of much more comprehensive and responsive video surveillance. Alerts from the video analytics system are fed through XProtect®, and into the Port’s C4 platform, where they are integrated with other alerts to create improved overall situational awareness. The advantages: Several strategic elements are deployed in the port’s surveillance network, and these elements work in unison to create complete behavioral analytics. The biggest advantage seen by the port is the ability to have the dispatchers, through the C4 common operating picture, pull up all camera views that they need to address an alert or an incident. It is also easy to add more cameras to the port’s surveillance network (which the Port did in conjunction with the installation of a new radar system from DMT), since the Milestone open platform supports the largest variety of manufacturer models. A Top Hub in Our Nation’s Oil Supply Chain About 80 percent of all Gulf oil comes from deepwater, and Louisiana’s Port Fourchon services more than 90 percent of the Gulf of Mexico’s deepwater activities. In addition to being the premier service base for the Gulf’s tremendous domestic hydrocarbon supply, Port Fourchon is the land base for Louisiana Offshore Oil Port (LOOP), which handles 10 percent of imported oil. Port security and the police have their work cut out for them, ensuring the nation’s oil supply, the workers and vessels, and every piece of equipment used to transport the product, are kept secure on a day-to-day basis. The previous surveillance system, installed more than a decade ago, was not up to the standards required by the Port for its new C4 installation. Many members of the Port’s security department and police force experienced difficulties with the old video system for its less-than-user-friendly interface, slow feeds, minimal storage and need for more cameras. "Alerts come right through the port’s Milestone XProtect setup. We can provide a brief clip of any target, time-and-date stamp it and inject it into the alarm" “We all agreed that our new video management system should be easy to integrate and allow us to dovetail with our legacy equipment while having an opportunity to shop around for upgraded hardware without any proprietary restrictions,” stated April Danos, Director of IT, Port Fourchon. “The ability to scale up over the years to increase the port’s protection was another very important aspect that needed to be addressed with the incoming VMS solution.” Key points in the port’s request for proposals included a system with minimal maintenance requirements, video display in real time, user-friendly operation and the ability to easily integrate a variety of already installed and soon-to-be-installed components: new servers, cameras, and analytics software, for instance. Milestone XProtect Enterprise VMS was chosen and implemented by Milestone certified partner Convergint Technologies. GLPC-C4 Priority 5’s Touch Assisted Command and Control System (TACCSTM) powers the Port’s C4 system. TACCS is an all-hazards command and control operations platform that integrates the VMS inputs with other data feeds to support the Port’s security and situational awareness requirements. Developed in response to requirements by the Department of Defense, the platform aligned with Port Fourchon’s vision for a centralized system into which all elements would be integrated, providing directors and police with full coverage of the analytics, radar, access control and security systems. With input from the Port and other early adopters, TACCS and the C4 system have evolved over the years, and now provide wide area situational awareness and response capabilities to Port Fourchon's Harbor Police dispatchers, Lafourche Parish Sheriff’s Office, the parish EOC, LOOP, and the Port Administrative, Operations and IT departments. “Our goal is to enable the Port to use TACCS and its open architecture to create the most comprehensive and flexible situational awareness solution possible,” said Joe Kammerman, Vice President of Priority 5. “Working with other companies such as Milestone that design their solutions around open architectures has proven to create a real value to customers, especially in today’s environment where budgets are tighter and people need to do more with less.” “Many companies claim to provide an integrated system, but what they deliver is more likely to consist of a large number of windows scattered on a screen, without any data integration,” noted Danos. “Milestone’s integration of video management and very detailed analytics literally gives our operators one single data feed through which the port’s entire surveillance system can be readily accessed as needed. We don’t miss a beat, which is priority number one when dealing with the safety of those at the port.” Several C4 stations throughout the port contain command centers equipped with Milestone The Setup Several C4 stations throughout the port contain command centers equipped with Milestone: three within the main office in Galliano, LA, one setup two miles from the port in the harbor police headquarters and one in the port itself. The LOOP system is networked into the Milestone software and Lafourche Parish Sherriff’s Office, with access to the port’s live feeds. The Federal Emergency Management Agency (FEMA) is also connected to the port for cases of emergency. Each registered user in the port security team has immediate access to Milestone video archives, going back as far as two months. “We have a good mixture of different makes and models of camera hardware and different analytics strategically deployed. We are very pleased with the way Milestone’s open platform enables us to explore multiple opportunities without worry of technology being rejected or reworking our entire system,” continued Danos. “All of the systems we implement in the port are brought in with the security factor in mind. Milestone has been very impressive as we adapt our system to improve operations every day.” All of the port’s surveillance systems work in unison with a behavior analytics system. Milestone is the only interface that can process this large amount of information, according to Bruce Whitaker of BRS Labs. “Alerts come right through the port’s Milestone XProtect setup. We can provide a brief clip of any target, time-and-date stamp it and inject it into the alarm. The users are looking at real-time video with the alerts built right in. No event goes unseen.” The Benefits Milestone XProtect is a day-to-day video management system, providing the video inputs and archives to the officers at the port to protect against criminal activity and helping to identify damage done to the docks or vessels that have been left unattended for long periods of time, among numerous other activities. The Milestone video product feeds the C4 common operating picture, enabling the dispatchers to maintain the big picture while having the ability to monitor video surveillance throughout the port. There are hundreds of continuous activities going on at any time. With all systems integrated, the officers can concentrate on security itself, not worry about the system working properly. “Nothing held up to the qualities of Milestone when we were researching for the port software integration,” stated Whitaker. “During the selection process, its capabilities were front and center. If we had any limit on our VMS options, we wouldn’t have a fraction of the benefits the port offers its security team now.” “The port has transformed its security platform to a new level,” concluded Danos. “We are working to be as far-sighted as possible, with the integration of our numerous best-of-breed applications, so the C4 system will always provide the highest level of maritime domain awareness. Starting with the Milestone open platform has allowed us to integrate numerous video applications through it, and the entire port is benefiting immensely.”
The Sabine-Neches Waterway runs 55 miles through Jefferson County, Texas, to the Gulf of Mexico, and includes the number-one commercial and military out-load port in the United States. It is the fourth largest port in terms of processed tonnage. A vast waterway traffic-monitoring network has been deployed to ensure all vessels (civilian, military and commercial) can safely navigate the waters with minimal interference such as collisions or other traffic stoppage. A new surveillance system also monitors the many petroleum refineries that line the channel. Backed by a Verizon Wireless 4G connection, the county cameras reside along the Sabine-Neches Waterway, networked through Milestone XProtect Enterprise for managing high definition video, live vessel movements and incident reporting. “Milestone’s open platform IP software is truly the best on the market. It integrates with all of the cameras seamlessly. Milestone XProtect provides the sheriff’s department with more high definition screen images and significantly better views of the waterway than the previous system. Now our system’s design provides live video and pushes to tablets, smartphones, dispatchers, and personnel on watercraft, who are given access to the video.” Mark Nolan, Knight Security Systems The Challenge Securing and monitoring 55 miles of waterway with traffic, including vessels ranging in size from small tugboats to huge tanker ships hauling hundreds of tons of oil and other commodities. When an incident is called into port security, the port authorities must assess the situation and respond immediately. Through the Milestone interface, reported incidents are checked on video to determine if the port must close or can continue operating. Closing the port for any amount of time is an expensive procedure, so having virtual eyes on the scene is imperative to operations. The previously installed system was only viewable and navigable in a control station building. The Solution Knight Security Systems designed and installed a Milestone XProtect Enterprise IP video surveillance solution with AXIS Q1604 and Sony SNC-ER550 cameras and more than eight terabytes of storage to provide 24 hours of monitoring. With the Milestone Mobile client, the sheriff’s department and port authorities have instant access to video at a moment’s notice, from anywhere. A Verizon Wireless 4G network for reliable and redundant operation powers the entire system. The Advantages The Milestone XProtect solution consolidates every one of the 24-hour monitored cameras into one centrally managed solution, viewable by all administrators in their respective offices, in the main monitoring station and on mobile devices. With high-level national security implications, live camera views and the ability to quickly check recorded video is essential to the port’s operational standards for efficiency. Every second between an incident report and confirmation of the validity of the report is crucial to the response process. A Vital Artery For US Oil Imports As the fourth largest port in the U.S., Port Arthur in Texas’ Jefferson County is the number-one crude oil destination for foreign tankers, as well as the number-one commercial and military out-load port. Hundreds of vessels are processed through the channel each day, making their way from other domestic ports and from all over the globe into the Gulf of Mexico and up the Sabine-Neches Waterway. With oil refineries and other critical infrastructure lining the 55 miles of river bank through Jefferson County, the sheriff’s department required a sophisticated security surveillance system to monitor waterway traffic and incidents. They need to ensure the safety of those working and traveling through the port, and to keep traffic flowing for the sake of commerce that relies on a clear waterway. With Milestone Mobile client, the sheriff’s department and port authorities have instant access to video from anywhere The Problem Previously installed systems relied on T1 lines, leased communication lines and microwave communication methods. Jefferson County was relying on outside partners to host landing points and was constantly provided low definition video. The area is scattered with low-lying areas and swamps, which limited coverage for the low-capacity T1 lines which were easily corroded from damp conditions and salt corrosion. When monitoring the video during and after an incident, a command center was the only place where the sheriff, Coast Guard or port officials had access to the video. When looking to completely upgrade the county’s river surveillance, officials contracted Texas-based Knight Security for a better solution – one that would provide nearly lossless access to video at a moment’s notice, even for those stationed away from the central command center. “Our goal was to provide high-definition screen views and more efficient monitoring of the waterway,” stated Mark Nolan, Sales Engineer, Knight Security Systems, Gulf Coast Region. “The new video system was specifically designed to capitalize on the unique areas of the Port. We now have camera ‘eyes’ located on an array of tall locations in challenging environments. Coupled with Milestone XProtect, the system provides advanced coverage throughout the entire waterway. We are able to provide live video and push out to tablets and mobile devices to numerous dispatch stations, personnel on watercrafts and others to have immediate access to any incident.” Protecting the Port The only way to access Jefferson County through the waterway is via Sabine Pass, TX or through two entry points on the Intracoastal Waterway. With an advanced communications system and screening process, no vessel is unaccounted for. The cameras act as verification to confirm radio transmissions. The Vessel Traffic Service (VTS) at Port Arthur acts as the “keepers of the gate” aided by the Milestone video management solution. VTS Port Arthur trained operators scan the waterways efficiently and effectively, 24 hours a day. VTS issues advisories and works to minimize blind spots utilising cameras and radar. Activities are monitored with the aid of the Milestone XProtect interface. Whether it’s a dredge, accident, or other incident; almost every vessel, regardless of size, is within a camera’s field of vision. “If we pick up a radar blip that’s not transmitting an identification signal, it is imperative to identify that blip before it enters the port,” explained Michael Measells, Director of Vessel Traffic Service. “The cameras can do what radar can’t achieve. We can put an eye on a vessel through the Milestone XProtect software, allowing us to know what’s moving from a marine safety and security standpoint. That’s the number-one mission.” Uniquely Stationed Surveillance Points Cameras line the river and port entrance, placed in strategic locations from the roofs of buildings to the top of the Verizon Wireless 4G towers. A Jefferson County Sheriff helicopter also hosts a mounted camera ready to be called into action at any time, whether it’s monitoring an incident or making rounds. “Our cameras feed the entire system and with the added support of the 4G LTE, the chances that we’ll be blacked out are very low. Nearly all aspects of the system have a redundant counterpart,” stated Measells. “We’ve been up and running as a group for eight years and other than hurricanes we’ve never had a shut down due to the system.” Knight Security Systems can monitor the status of the sheriff’s cameras and immediately notify the client of a camera outage, which might not have been noticed by the authorities if they’ve not checked their mobile device. Downtime is completely minimised with the proactive monitoring and Milestone system alerts. “We’ve adapted to the ease of application, connectivity and versatility of the Milestone interface very quickly – it’s become so easy to use. It’s something we can just access without really putting too much extra work into it,” stated John Moore, Electronics Materials Officer, United States Coast Guard. “Milestone is always up and running and it loads extremely fast on any mobile operating system.” The system also includes a rapidly deployable camera system that can be connected to a generator and a camera on a portable frame to easily access the waterway. It can be deployed and launched live into the Milestone system via local cell towers within minutes of a reported incident. “The versatility of our Milestone setup also allows us to remotely provide access to our Sector Command Center in Houston so they can view any potential issue,” Moore continued. Incident Confirmation and Control "The versatility of our Milestone setup also allows us to remotely provide access to our Sector Command Center in Houston so they can view any potential issue" The port is a vital, active entity, responsible for millions of dollars in assets and manpower. If an incident is reported to the Sheriff’s Department or Coast Guard, which isn’t uncommon, there are established procedures to follow before any response is made. A response for any event, whether a boating accident, cargo spill or personal injury, has the potential to shut down the critical channel for an extended length of time. When an incident is reported, officials must immediately confirm the report. Once confirmed, the proper authorities are contacted and ground or water personnel deployed as needed. The sheriff’s department jurisdiction covers the entire 55 miles of critical infrastructure, so mobility is vital. “I’m not monitoring the lines 24 hours a day personally, but if I get a report of an incident, I’ll pull Milestone Mobile up on my tablet or phone to assess the situation,” stated Deputy Chief Mark Dubois, Jefferson County Sheriff. “XProtect helps us respond quickly, allowing us to pull up video from any particular time and cameras immediately, from any location, to confirm or deny an event.” “With our camera coverage, we can move from evaluation of a report to initiating a response in a matter of minutes, if not seconds,” Moore continued. “There’s time and money there. Once we confirm, all responders’ mindsets are immediately shifted into ‘response’.” The Benefits of Scalability and Usability Quickly allowing access to live and recorded video, Milestone can handle a large number of cameras should the sheriff’s department decide to upgrade or add more hardware devices to the monitoring solution. “Overall, it used to take a lot more time before the sheriff could react to an incident, which could have been a life-or-death difference over a few minutes,” continued Nolan. “Milestone provides the open platform capability, allowing the end user to stay current on the latest and greatest software, and scaling up without changing the entire system from the ground level up.” Training was quick and efficient among the three user groups -- field users on the ground and water, and users in the office reporting on analytics, recording and searching archives. Knight Security Systems created different user profiles and tailored training sessions for each group, showing them exactly the views and functions they will regularly access, rather than diving into processes that would not be relevant to their specific duty. In total, 40 personnel were trained on Milestone, from ‘power users’ to those who use the system casually or view cameras sporadically. Screen images are used for numerous activities besides security, including studying tow configurations, training, and exporting photos and data to port partners. “This is a high-traffic waterway and with a limited width, there are bound to be close calls and incidents,” said Measells. “It’s just good to have more eyes on each vessel. The cameras are high resolution enough to read a soccer player’s jersey number from a mile away in low light! We’re sending photo-quality screenshots throughout our network, which is incredibly valuable for investigations”.
