Bosch Digital video recorders (DVRs)(83)
It combines network video recorder (NVR) server, storage array, client workstation and integrated video management software in a ready-to-go ‘system in a box’. Installation, set-up and operation are so simple that no certification or special training is required. High performance, minimal storage costs With real-time recording of SD (Standard Definition), HD (High Definition) and Megapixel video sources at resolutions up to 2048 x 1536 (3 MP), the BRS Appliance delivers superb image clarity and detail. It supports a variety of compression technologies including H.264 Main Profile, ensuring high performance while keeping storage costs low. Centralised system management The BRS Appliance interfaces with a variety of your security and building management systems including fire and access panels, ATM and POS terminals, and number plate capture and video content analysis solutions. It provides quick and easy access to information from anywhere in the network, even over remote, low bandwidth WAN connections. A convenient, scalable and user-friendly interface allows various locations to be monitored simultaneously. Secure connections For high security installations, the BRS Appliance has several features that make it ideal. They include an automatic log-off, with a configurable time interval of inactivity, to increase protection against unauthorized access. Also, two different pre- and post-alarm recording times can be set for each camera, while audio can be configured by event. Extending potential The BRS Appliance is fully compatible with our DiBos recording solution, enabling you to easily extend existing systems to support Bosch H.264 SD and HD IP cameras – providing a future-proof migration path. To ensure you find a solution that fits your needs several models are available, including both stand-alone ‘all-in-one’ and rack-mounted server units. Key applications Banks Retail Schools Fueling stationsAdd to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 4096 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 4096 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 1024 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 1024 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 2048 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 3 out, 2048 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 375 x 290 x 50, 2.5, 12 V DC, 35 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
16 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 6 out, 4096 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 16 in, 6 out, 4096 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 4096 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 1024 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 1024 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 2048 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
4 channels, Real Time / Timelapse / Event recording, Inbuilt Multiplexer, 4, 2048 GB storage, 30 fps storage rate, H.264, 960 x 576 resolution, PAL / NTSC, USB / DVD+R/RW, HDD, DVD, G.711, Simulatneous Live, Recording, Playback, Archive, 30, 440 x 420 x 70, 5.5, 100 ~ 240 V AC, 55 W, 0 ~ 40 C (32 ~ 104 F), < 93Add to Compare
From the Bosch small business portfolio of professional CCTV productsMany small applications - such as shops and retail stores, pharmacies, gas stations, schools and small offices - often lack CCTV systems of sufficient quality for reliable surveillance. Not so with Bosch small business products. Covering analog, IP network and HD (High Definition) systems, they offer great value for money, with professional performance and great imaging quality at very competitive prices.Typical small analog video solutionProviding extensive flexibility, an analog solution could combine WZ Series integrated infrared (IR) dome and bullet cameras, Indoor MiniDomes and our Video Recorder 400 Series. Making perfect standalone, non-networked systems, our analog products ensure excellent image quality in difficult lighting, and are great for new installations or when complementing existing analog components.Typical small IP video solutionFor anyone wanting to go digital with small network systems, the Bosch IP 200 Series cameras are an obvious choice, with lots of different models to cover a wide range of applications / locations. Options include indoor fixed-body, dome and IR dome models and outdoor IR bullet camera. Bosch network video systems offer superior convenience, cost-effectiveness and overall efficiency. Using local area networks or even the Internet, they provide extra control over CCTV systems with improved ease of operation and centralised management.Typical small HD video solutionIdeal for new installations, an example small HD video solution could comprise fixed-body and dome high definition cameras from the Bosch IP 200 Series. These cameras are perfect for applications requiring fine detail and for people preferring the coverage offered by the widescreen image format. To ensure true HD imaging, each component is specifically designed for HD technology - HD-optimized from scene to screen.Now everyone can afford the bestBosch small business solutions carry the same high quality and reliability as any product in the Bosch portfolio, as the standard 3-year warranty guarantees. Installation, set-up and operation are all easy and, with minimal servicing, time and costs are kept to a minimum. Also, as they are available at local distributors, choosing the right-fit solution has never been easier.With such a comprehensive offering of cameras, video management options and accessories, there's a Bosch small business solution to fit virtually any application - at an affordable price.Add to Compare
Browse Digital video recorders (DVRs)
Digital video recorder (DVR) products updated recently
In today’s market, efficient use of bandwidth and storage is an essential part of maintaining an effective video surveillance system. A video management system’s ability to provide analysis, real time event notifications and crucial image detail is only as a good as the speed and bandwidth of a surveillance network. In the physical security industry, H.264 is the video compression format used by most companies. Some companies also employ H.264 enhancements to compress areas of an image that are irrelevant to the user at a higher ratio within a video stream in order to preserve image quality for more important details like faces, license plates or buildings. The H.265, H.264’s successor, will be increasingly used for compression in the future. Some companies are already using H.265 in their cameras and video management systems, while a host of other manufacturers are certainly preparing for its broader adoption in the years to come. Video Compression Technologies Reduced bandwidth and storage requirements are the primary benefits of video compression technologies Reduced bandwidth and storage requirements are the primary benefits of video compression technologies. In some cases, H.265 can double the data compression ratio of H.264, while retaining the same quality. Increased compression rate translates into decreased storage requirements on hard drives, less bandwidth usage and fewer switches – all of which reduce overall costs of system ownership. H.265 compression delivers a lower bitrate than H.264, which is relevant to end users and integrators because the lower bitrate reduces strain on hardware and can reduce playback issues. It’s very important that the compression format that is used is supported in all of the different components of a system: cameras, desktop computers on which the VMS is running and the VMS itself. It is also good for end users and integrators to understand the basics of video compression. Having a basic understanding of compression allows users to tweak settings to reduce bandwidth usage even more. Many cameras come with default settings that can be changed to ultimately reduce costs. ONVIF Physical Security In the physical security industry, ONVIF is working to incorporate into its specifications the use of new formats such as H.265 but is not directly involved in developing the compression standards themselves. With Profile T, the new ONVIF video profile released will employ a new media service that is compression agnostic. This means that it can support new video compression formats, including H.265, as well as new audio compression formats, with the ability to include new video and audio codecs as needed in the future without having to redesign its media service. In the physical security industry, ONVIF is working to incorporate into its specifications the use of new formats such as H.265 Standardization organizations that are directly addressing new compression standards include the International Telecommunication Union (ITU), the Moving Picture Experts Group (MPEG) and a joint commission of the International Organization for Standardization (ISO)/International Electrotechnical Commission (IEC), which is addressing the coding of audio, picture, multimedia and hypermedia information. Other compression formats on par with H.264 and H.265 are being developed by companies such as Google. H.265 Compression Formats Using products that employ H.265 compression will reduce costs through bandwidth reduction, as will changing default settings on cameras, which are often conservative. Having a basic understanding of compression formats and how to tweak camera factory default settings also gives integrators the ability to further reduce bandwidth for added costs savings and increased system performance. These enhancements will analyse which parts of an image are most important and adjust local levels of compressions accordingly It is also worth noting that H.265 enhancements will likely be developed by camera manufacturers to further reduce bandwidth, as was the case with H.264. These enhancements will analyze which parts of an image are most important and adjust local levels of compressions accordingly. While H.265 itself is ready for prime time, its value as a tool for IP-based surveillance systems is dependent on support for the codec in all parts of the system – the VMS, server hardware, graphics cards and camera. Though widespread H.265 adoption is predicted, providers of these components are jumping on the H.265 bandwagon at different rates of speed. ONVIF is including support for H.265 in its new video profile, Profile T, because it believes it will become the most widely used compression format and ONVIF recognizes the need to anticipate that migration as a future need of the industry. The new media service, which will be implemented with Profile T, will be future-proof in that when new compression formats are released in the future, ONVIF can adopt them very quickly. That flexibility will definitely help integrators.
According to IHS Market, it is estimated that there are over 60 million security cameras in the United States, and other reports say these cameras capture more than four billion hours of footage per week. Over the last decade, IP camera technology has dominated the conversation as it has provided users with a broad offering of enhanced image quality and features. With a large percentage of existing security systems relying on analog, many end users looking for high definition (HD) video quality have been forced to take on a complete system overhaul. Infrastructure Overhaul For HD Video To make the switch, customers would need to change everything, from cameras to hardware to wiring– not to mention the lengthy installation process that would ensue. IP cameras also require higher Internet speeds and more cloud space. Whether constrained by budget, bandwidth or storage, many end users have been unable to adopt this new video surveillance method.Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike. By utilising the current Coaxial cables, this offering yields high definition video, while requiring minimal infrastructure changes and is an optimal surveillance choice for security customers. Plus, with new advancements and updates being made frequently to this technology, there is a solution for every security need. The enhanced alternative of HD over Coax has been warmly welcomed in the security industry, thanks to its simple solutions and ever-evolving features. Many new analog HD cameras are “plug and play,” able to connect directly to existing Coaxial cables. This eliminates the need for a complete system change, creating cost-savings for the end user and an enhanced video quality offering. Easy Solutions For HD Video As a result, integrators can cost-effectively upgrade their customer’s surveillance solution while using their legacy infrastructure, making it an attractive option for end users and an easy sell for dealers. Latency in video is another common issue with network-based camera systems, where even the slightest delay in video surveillance can hinder security response HD over Coax cameras themselves are always expanding and evolving to meet a wide array of security needs. With the introduction of fisheye and multi-sensor cameras, users now have a multitude of coverage options, not to mention the introduction of 4K bringing resolution options to the same level as IP. Some newer technologies are even touting 4K cameras paired with 4K digital video recorders (DVRs) made specifically for analog systems. Longer cables grant transmission for up to 1600 feet, double the distance of standard analog solutions, and triple that of IP systems. This single cable is able to transmit both HD video and audio. Recently, broadcast quality audio over Coax has become available in limited models, a substantial improvement over older analog technology, which was unable to transmit audio. Stopping Video Delay Latency in video is another common issue with network-based camera systems. Even the slightest delay in video surveillance can hinder security response. IP cameras are forced to compress and packetize their video for transmission. The outcome of this is a reduced number of images per video, which in turn causes delay. HD over Coax on the other hand, delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity. Additionally, the point-to-point transmission delivers uncompressed video free of lag. Another touted benefit is that, unlike IP networked cameras, analog systems provide a more secure video transmission. With so much sensitive information housed on a businesses’ network, adding another point of network access through an IP camera can create concerns for cyber security risks. HD over Coax delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity Preventing Network Hacking With HD over Coax, the physical connections between the camera and DVR prevent network hacking. By keeping the video surveillance system offline, security professionals are able to direct their attention to the physical threats at hand, rather than having to focus on deterring cyber security risks. One of the primary difficulties of deploying HD video solutions is the fact that many older systems utilize a wide variety of HD standards and platforms. To make matters more complicated, after HD over Coax was brought to market, manufacturers raced to create their own version of this technology. Today, the most popular proprietary standards are HD-CVI, HD-TVI and AHD. However, integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible.Integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible Diversifying Surveillance Through One DVR To combat these issues, manufacturers have introduced products with more flexibility to their portfolios. One example of this is the penta-brid DVR which grants the ability to seamlessly integrate multiple technologies deployed across one application. This means that systems with diverse camera brands and technologies, such as a mix of HD-CVI, HD-TVI, AHD, analog or IP, can be connected through one DVR. For many end users with legacy analog systems, penta-brid DVRs give them greater freedom to choose between a variety of solutions, rather than being limited to one option. With video resolution increasing, the space needed to store the footage is similarly rising. Penta-brid technology has been able to adapt to these evolving needs, giving users ample storage space to house the HD and 4K surveillance video with some of the newest models including H.265 compression. HD Casino Surveillance Made Simple For casinos, HD images are critical for identifying unauthorized personnel and unlawful behaviours to create a safe environment for guests and staff While HD over Coax is beneficial to many end users and integrators, those in the casino and hospitality markets find it crucial. With a combination of high profile guests, large amounts of cash on hand, constant crowds and strict industry regulations, reliable video surveillance is a must. Deploying new IP systems comes at a stiff price. When looking to upgrade their video surveillance, casinos must also be mindful of the installation process. When moving to an IP-based system, ripping out old wires and replacing them with new is the standard practice. This practice can be both disruptive and costly, not to mention gaming regulations require casino activities be monitored at all times so a complete system shutdown would result in revenue loss. This cost can be hard to justify, especially when the current legacy analog system remains in working condition with only the lower image resolution to date it. For these scenarios, the most cost-effective option is to leverage the legacy infrastructure, replace the existing cameras with new devices, and reap the benefits that HD video has to offer without any lapse in security. For casinos, HD images are critical for identifying unauthorized personnel and unlawful behaviours to create a safe environment for guests and staff. HD over Coax cameras now offer the same resolution as IP cameras with a plug and play approach, that cuts down on expense without sacrificing quality. For businesses and applications that are unable to adopt IP technology, whether it be cost or time prohibitive, HD over Coax now features most of the same benefits IP has to offer without breaking the bank. By providing clear images in real time, maximizing existing infrastructure, and affording cyber security benefits, HD over Coax provides an attractive solution for many end users and integrators.
Dollars spent by video surveillance customers must go towards ensuring high-availability capture, storage and on-demand access to live and archived video. Reaching this goal mandates high-availability of independent components – camera, network, storage (edge, external), internet connectivity, display, all Video Management Software (VMS) components and an architecture that can take advantage of this. In this note, we focus on seeing our way through to a video surveillance architecture, that provides high availability storage, access to live and stored video content. Of all options available to store recorded video, edge recording is the only one that is unaffected by network failure Edge Recording Of all options available to store recorded video, edge recording is the only one that is unaffected by network failure. This makes edge storage a must-have. But, this has some limitations at present: Edge storage capacity is limited. Edge media has a short lifetime, rated only for thousands of hours of continuous recording. Most cameras are not secure and physical damage to the camera could lead to catastrophic loss of edge stored content. As storage and compression technology evolve, the constraints imposed by (1) and (2) could go away. However, securing cameras will continue to be a barrier for most installations. Secure External Storage It is thus imperative to also store video in secure external storage. Such an architecture uses edge storage to fill in content gaps created by network, external storage outages. As edge storage technology improves, larger gaps can be filled in, but one will always need external storage. By our definition, ‘external storage’ is a solution stack that includes storage media and all software (including VMS) that provide access to this storage. Access To Live And Archived Video Access to live video can either be met by external storage or directly by the camera Every surveillance solution needs to provide access to live and archived video. Access to live video can either be met by external storage or (and) directly by the camera. All things being equal, having the camera directly provide live video access, is a higher-availability solution. There is dependence on fewer components in the chain. Solutions in the market use one of the above two approaches for access to live video. Due to limited capacity and low physical security of edge storage, it makes sense at present, to have external storage meet all requests for archive video. Thus, we are led to an architecture that has heavy dependence on external storage. Dual-Recording For high-availability, external storage must be architected with redundancy. Ideally, independent components that make up external storage – storage media, associated hardware and software (including VMS components), should be individually redundant and have smart interconnectivity. However, solutions in the market rigidly tie these components together. Failure of a single component causes failure of external storage. For e.g. hardware failure of a server causes VMS component failure AND storage failure. DR provides a smart way to provide high-availability for external storage For these solutions in the market, high-availability is achieved by having additional external storage units that step-in during outages of primary units. If these additional units continuously duplicate primary units, access gaps are minimized, and archive access is un-affected during primary unit outages. This is the idea behind Dual-Recording (DR). To meet cost budgets, these additional units can be configured to store subsampled (framerate, resolution) video content. A small number of additional units can support concurrent outages of all primary units. A few-to-many redundancy. Rising Need For Dual-Recording Most cameras cannot be physically secured, and video content produced by a camera must be stored externally. Many VMS solutions use external storage to service live video access requests. Edge storage limitations impose restrictions on edge archive access at present. So, external storage is used to service requests for archive access too. Thus, a surveillance system ends up being over-dependent on external storage. DR provides a smart way to provide high-availability for external storage. As edge storage improves, it will be able to service archive access requests. VMS software will need to evolve, to use this capability smartly.
One of the largest public train operators in the United Kingdom, Southeastern Rail Network, now relies on a smart video security solution from Bosch Security Systems to secure twelve train depots, including five unmanned locations, against theft and intrusion. The fully digital video surveillance system presents a significant upgrade to the British train operating company, which provides train services between London, Kent and parts of East Sussex and transports 6, 40,000 passengers each weekday on its 392 trains. built-in Intelligent Video Analytics Powered by cameras featuring built-in Intelligent Video Analytics, the solution was installed and configured to the specific requirements at the train depots by Bosch integration partner, Taylor Technology Systems Ltd., over the course of six months. Video security system relies on machine learning algorithms to automatically sound alarms on security threats Fully operational at all twelve locations, the video security system relies on machine learning algorithms to automatically sound alarms on security threats, such as intruders and perimeter breaches. Beyond security applications, the system also tracks important metadata on the arrival times of trains, while also monitoring deliveries at the train depots, among other AI-assisted functions that it carries out. IP-based cameras with Starlight technology The cameras portfolio installed across the twelve depots replaces an analog legacy solution with IP-based security cameras from the Flexidome, Dinion, and Autodome product lines of Bosch Security Systems. These smart cameras include Bosch’s Intelligent Video Analytics capabilities as a built-in feature, ensuring that the most relevant video data can be precisely applied to the requirements of the train depots. Because night-time security and surveillance is critical, especially at the five unmanned train depots on the network, the Bosch cameras rely on Starlight technology to provide full intelligent analytics at night and in low light levels. The Starlight technology supports color filtering down to a light level of only 0.0077 lux, so as to deliver detailed monochrome images where other cameras show no image at all, and guard against intruders and unauthorized entry around the clock. Featuring digital ‘trip wire’ to counter false alarms Highly resilient against false alarms, the smart cameras can detect movement at the perimeters of the train depots using a digital ‘trip wire’. In case of a security breach, the system alerts Southeastern Rail Network’s watch personnel, who can view live camera footage, as well as recordings of incidents for heightened situational awareness and total perimeter security. Instead of relying on the pre-configured capabilities, such as vehicle tracking and more, security personnel can also use the built-in camera trainer function to ‘teach’ new functionality, such as detecting certain types of objects or situations. Remote video recordings storage with Divar recorders Recordings from the depots are safely stored and managed remotely with Divar recorders in encrypted format As an integral part of this end-to-end Bosch security solution, recordings from the depots are safely stored and managed remotely, using Divar all-in-one recorders in encrypted format. When looking at the bigger picture, the video security solution adopted by Southeastern Rail Network is part of an industry-wide evolution from cameras as mere video capturing devices to smart sensors capable of collecting rich metadata. Insights beyond security This metadata unlocks unique insights beyond security, including video analytics at the train depots that support applications such as monitoring deliveries to onsite buildings, providing access to personnel and logging the arrival and departure times of incoming trains. The system thereby not only ensures that all train depots remain fully guarded and protected 24/7 against criminal access, but also provides a data-based foundation to keep efficiency gains and cost savings on track in the long run.
Located 40 kilometers outside the Russian capital, the new Mercedes-Benz passenger car factory is a showcase for Industry 4.0 automotive manufacturing. To ensure the safety of more than 1,000 employees at the massive facility, Bosch provided a fire alarm and security system, replete with voice evacuation capabilities to meet the specific safety needs of modern-day car factories. Future of car manufacturing Walking into the main manufacturing hall of the new Mercedes-Benz Cars plant in the Moscow region is to see the future of automotive production. Amid glass walls and high ceilings, robots and humans work side-by side to assemble the company’s most popular limousines for the Russian market. From chassis welding to windshield installation to painting, the plant combines all production steps in the same building as part of a ‘one-roof concept’. But from a fire safety perspective, the ‘one-roof concept’ with its tall factory ceilings and open floorplan poses challenges. The reason: Conventional, point-type fire detectors exceed their performance limit when it comes to detecting smoke particles inside such a vast, air-conditioned space. Working closely with the client, experts of Ateksis, the system integrator who lead this project, realized that early fire detection would take a solution just as innovative as the futuristic car factory itself. Safety for automotive factories They can detect fires in the beginning stages (called the “smoldering” phase) even before visible smoke is released Additionally, Mercedes-Benz required a centrally controlled combination of intrusion alarm and video security to guard the entire perimeter of the 85-hectare facility with its total of seven buildings. And could the solution be ready within a few weeks for the plant’s grand opening featuring international dignitaries? Working on a tight timeline, the team of Bosch and Ateksis experts selected a fitting smoke detection technology: aspirating smoke detectors. Perfectly suited for large warehouses, the detection units are located within a pipe system that constantly ‘inhales’ samples of air, which are checked for smoke particles via intelligent signal processing technology. As a result, the light-based detectors achieve smoke sensitivities as precise as 0.05%. They can detect fires in the beginning stages (called the “smoldering” phase) even before visible smoke is released. electrical interference for reliability Aspirating detectors also pinpoint the exact location of fires, thus reliably preventing major damage in most cases. The system also suppresses environmental factors that typically cause false alarms in car factories, including dust, flying sparks and electrical interference for maximum reliability. “The Mercedes-Benz project is an important reference for us. It shows the level of integration and customer focus made possible by Bosch solutions. Our system has succeeded in meeting the specific needs of automobile manufacturers in the next generation of car production facilities”, said Ivan Konukhin, Bosch Security and Safety Systems Russia. audio sound quality The ceiling loudspeakers are equipped with a metal fire dome to adapt to the in-air handling spaces Amid the acoustic conditions inside the vast production plant, a total of 650 horn and ceiling loudspeakers from Bosch deliver sufficient volume and intelligibility. The horn speakers offer a wide opening angle to broadcast sound across factory floors while offering protection from water and dust, as well as the corrosive effects of industrial environments. What’s more, the ceiling loudspeakers are equipped with a metal fire dome to adapt to the in-air handling spaces of the automotive plant. The cabinet loudspeakers are certified according to the fire evacuation EN54-24 standard for reliable performance under emergency conditions. Overall, this level of audio sound quality directly serves to keep workers secure and informed, especially if evacuation becomes necessary. automatic fire detectors In the bigger picture, the total of 248 aspirating detectors inside the main production hall are centrally networked via Modular Fire Panels 5000 series and connected to more than 2,500 automatic fire detectors installed throughout six additional administrative buildings on the premises. For maximum employee safety, clear voice and audio alarm is provided by the PRAESIDEO Digital Public Address and Voice Alarm System. With Smart Safety Link, the interfaced fire and voice alarm system offers a full control in case of emergency, including the customization of the fire verification time and the automatic process that can ensure a safe phased evacuation. To ensure full visibility of the premises and around-the-clock safety, the video security solution consists of 112 high-definition cameras from Bosch. While bullet and moving cameras secure the perimeter, dome cameras monitor inside spaces. Video Management System Integrated on the Bosch Video Management System, all cameras can be controlled by the on-site security team Integrated on the Bosch Video Management System (BVMS), all cameras can be controlled centrally by the on-site security team inside the control room. Bringing security full-circle, the video system has a direct interface with intrusion alarm system containing over 200 detectors. This seamless integration of all solutions on the Building Integration System (BIS) from Bosch enables a host of additional functions: for instance, the system alerts the control room when a fire detector is triggered and sends live images from the nearest camera for full situational awareness. Aspiration smoke detector As Ivan Konukhin at the Regional Representative Center North-West and South Russia at Bosch Security Systems explains: “The cooperative functionalities between BIS and BVMS components were programmed according to customer requirements in an uncomplicated manner via macros, which also supported a timely installation.” Bosch Security System’s solution consists of: FPA-5000 Modular Fire Panel Solution Smart Safety Link License key for voice alarm Aspiration smoke detector 2 pipe systems AVENAR detector 4000 PRAESIDEO Digital Public Address and Voice Alarm System Metal Fire Dome Cabinet loudspeaker, metal, rectangular Horn loudspeaker, 10W, 6x10" Ceiling loudspeaker, 6W, ABS MAP 5000 family IP4000i, 5000i and 6000 cameras AUTODOME IP Cameras Access Control System Bosch Video Management System Building Integration System
The Security Industry Association (SIA) has announced the 2020 winners of the SIA New Product Showcase Awards, the flagship awards program in partnership with ISC West recognizing innovative security products, services and solutions. Top among the winners – who were recognized July 9 during a virtual awards show – was Leica Geosystems, part of Hexagon, receiving the 2020 Best New Product Award. Since its inception in 1979, the SIA New Product Showcase has been the security industry’s premier product awards program. New products are reviewed by a panel of judges with extensive industry experience, and in 2020, following significant deliberations, the 30 judges presented awards for technologies covering 23 product and service categories. Leica Geosystems, part of Hexagon, received the Best New Product honor for its 3D Surveillance with Leica BLK247, submitted in the Emerging Technologies category. Building security The 3D Surveillance with Leica BLK247 is “a first-of-its-kind reality capture sensor for building security and operations,” said Leica Geosystems. “It is the latest product in the company’s BLK product line, a collection of reality capture, scanning and photogrammetry hardware and software. The BLK247 offers continuous, 24/7 LiDAR-based 3D monitoring and change detection within spaces. It does this using LiDAR, 3D digital fencing and continuous scanning to monitor buildings and spaces 24 hours a day, 7 days a week.” The prestigious Judges’ Choice Award was presented to Suprema Inc. for the Airfob Patch product, submitted in the Access Control Devices & Peripherals Hardware – Wireless category. “Airfob Patch is the world’s first mobile-to-RF-card signal translator, enabling mobile phones to communicate with the existing RF card readers,” said Suprema Inc. “Wire, batteries nor construction is required for installation. Airfob Patch charges itself by using the existing RF field signals transmitted from the RF reader. It transforms the RF fields into its own power source.” New Product Showcase Merit Award SIA is proud to present John Spooner with the 2020 SIA New Product Showcase Merit Award" Additionally, John Spooner – executive vice president at Alarm Detection Systems and an active volunteer judge in the SIA New Product Showcase program. Spooner received the New Product Showcase Merit Award, which recognizes an individual or company who, through their support of the New Product Showcase, demonstrates a commitment to the vision and mission of the program, contributes to its success and promotes the advancement of SIA and the security industry overall. “SIA is proud to present John Spooner with the 2020 SIA New Product Showcase Merit Award; John has not missed a single SIA New Product Showcase event since he began as an active volunteer judge in the program 17 years ago,” said Chris Grniet, chair of the SIA New Product Showcase Committee. “He has always been a fair and honest participant and has never hesitated to jump in and help whenever we need him. He has been exemplary in his commitment, participation and ability to help the group reach consensus.” Services and contributions “Following hours of panel-driven judging and technology demonstrations, SIA is thrilled to recognize the 2020 winners of the SIA New Product Showcase Awards for their innovative products, services and contributions representing the best new offerings in the market,” said SIA CEO Don Erickson. “SIA applauds all the honourees who received awards in 2020 and particularly Leica Geosystems and Suprema Inc. for standing out in this highly competitive field of entrants to earn the Best New Product and Judges’ Choice distinctions. Additionally, we congratulate John Spooner on receiving the 2020 New Product Showcase Merit Award in recognition of his many valuable contributions to this premier program.” Award winners The 2020 SIA New Product Showcase winners are: Best New Product Award Winner – Leica Geosystems, Part of Hexagon: 3D Surveillance with Leica BLK247 Judges’ Choice Award Winner – Suprema Inc.: Airfob Patch New Product Showcase Merit Award Winner – John Spooner, executive vice president, Alarm Detection Systems Category Awards Access Control Devices & Peripherals Hardware – Wireless Winner – dormakaba: BEST Switch™ Tech Access Control Software, Hardware, Devices & Peripherals – Wired Winner – Swiftlane: Swiftlane Access Control Honorable Mention – Altronix Corporation: Tango Anti-Terrorism/Force Protection and Biometrics Winner – Gibraltar Perimeter Security: G-1441 Ultra-Shallow Bollard Winner – IDEMIA: VisionPass Commercial Monitoring Solutions Winner – IronYun Inc.: AI NVR Edge Analytics Communications and Networking Solutions Winner – Axis Communications, Inc.: AXIS C8210 Network Audio Amplifier Convergence and Integration Solutions Winner – Blue Light: Blue Fusion Design, Diagnostic and Installation Tools Winner – Alarm.com: On-Site Wrap Up Emergency Communication Systems Winner – Verint: NowForce Emerging Technologies Winner – BioConnect: BioConnect’s Unified Mobile Access Solution Winner – IPVideo Corporation: HALO IOT Smart Sensor 2.0 Fire/Life Safety Winner – Kidde: Kidde Optica Smoke Detectors Hosted Solutions/Managed Services Winner – SiteOwl: SiteOwl Intrusion Detection and Prevention Solutions (Physical) – Wireless Winner – Alula: Slimline Touchpad Honorable Mention – Cartell: CW-SYS Wireless Driveway System Lock and Key Solutions Winner –Medeco: All Weather Padlock Honorable Mention – Abloy Oy: ABLOY® BEAT Mobile Solutions (Connected) Winner – CloudScann: Visual Intelligence Control Center (VICC) With VisualC3 Mobile Honorable Mention: Rapid Response Monitoring: rapidSMS Smart Home Solutions Winner – Alarm.com/Building36: Smart Water Valve+Meter Threat/Risk Management Software Applications Winner – Splan Inc.: SIVI™ – Splan Intelligent Visitor Insights Video Surveillance Advanced Imaging Technologies Winner – Axis Communications, Inc.: AXIS Live Privacy Shield Video Surveillance Cameras (HD/Megapixel) Winner – Bosch Security and Safety Systems: MIC IP Ultra 7100i Honorable Mention – Hanwha Techwin: PNM-9085RQZ Video Surveillance Data Storage Winner – Dragonfruit AI: Dragonfruit LiveArchive Video Surveillance Hardware and Accessories Winner – EIZO Inc.: FDF2711W-IP Video Surveillance Management Systems Winner – Airship Industries, Inc.: Airship EMS v5.4.5 During the 2020 SIA New Product Showcase virtual awards ceremony, in addition to the presentation of the overall and category-specific awards, attendees enjoyed hearing insights from New Product Showcase judges into innovations driving product advancements in the security industry.
