Hanwha Multi-sensor/Multi-directional Camera

Product Profile

Hanwha Techwin’s Wisenet PNM-9000VD multi-sensor/multi-directional camera provides quality images and modular lens configuration at an affordable price. This camera supports 30fps image capture and true 120 dB WDR without compromising frame rate for each of its two 5MP sensors. Each sensor has its own Wisenet 5 chip, providing a full suite of built-in video analytics including loitering, directional detection, fog detection, tampering, motion detection and objects entering or exiting an area.

Read more

Technical Specification

Make Hanwha Techwin
Manufacturer Hanwha Techwin America
Model code PNM-9000VD
Chip Inch Size 1/2
Color Type Color / Monochrome
Resolution TVL 2x 5MP
Megapixel Yes
Sensitivity lux 0.16
Digital (DSP) Yes
Indoor/Outdoor Outdoor
Electrical Specifications Voltage: PoE
Power Consumption: 12 W
Compression H.265/H.264 : Main / Baseline / High, MJPEG
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 2~1/12,000sec
Video Output CVBS : 1.0 Vp-p / 75Ω composite, 720 x 480 for installation
Network Properties Interface: RJ-45 (10/100BASE-T)
Network Protocols: IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Image Frame Rate: 30 fps
Physical Specifications Dimensions mm: 197 x 84
Weight g: 1250
Environmental Specifications Operating Temp oC: -40 ~ +55 C (-40 ~ +131 F)
Operating Humidity %: < 90
Protection: IP66, IK10
System Requirments Operating System: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Web Browser: Recommended Browser : Google Chrome, Supported Browser : MicrosoftInternet Explorer 11, Microsoft Edge, Mozilla Firefox (Windows 64-bit only), Apple Safari (Mac OS X only)
Additional info
  • Interchangeable 2 x 5 MP lens modules
  • 3.7mm, 4.6mm, 7mm fixed lens options
  • 30fps@all resolution (H.265 / H.264)
  • H.265, H.264, MJPEG codec, Multi streaming support
  • Intelligent video analytics, WiseStream II
  • Micro SD / SDHC / SDXC memory slots x 2
  • IP66, IK10, PoE
Download PDF version Download PDF version
